NetSure 512 Series DC Power System

The NetSure 512 Series, a compact -48/+24 volt 525 A DC power solution, features an advanced control unit, up to (30) positions for 2000 W high-efficiency eSure rectifiers or 1500 W -48 V to +24 V converters.


•High Efficiency – 96.2% efficient eSure rectifiers
•Wide Operating Temperature Range – rectifiers function at -40 °C to +80 °C (up to +65 °C without de-rating)
•Selectable AC Input - 120VAC, 208 to 240 VAC
•Supports Ethernet, SNMP V2 & SNMP V3, ModBus and RS485 communication interfaces
•Battery Management Capability
•ECO Energy Savings Mode
•NEBS Level 3 compliance and UL Listed
•Custom configuration file capability


•Minimize total cost of ownership with high efficiency eSure rectifiers
•Reduce the need for specialized cooling with rectifier high temperature operation
•Deploy the power system where 120VAC is the only input option
•Keep your network power source secure with encrypted controller communication
•Extend the life of your batteries with the available battery management tools
•Achieve energy savings with ECO mode, even at low loads
•Have peace of mind with this UL and NEBS power system
•Minimize installation time and drive planned network conformity with custom configuration files
•Optimize your battery capacity with priority and non priority load shedding
•Solar/Hybrid Capability – reduces grid dependency

Technical Specifications
